Home > Our products > Silentblocs > Conical rubber stop > Conical rubber stop D.50mm

Conical rubber stop D.50mm

Height 50 to 64 mm | Thread M8 to M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
Print

Conical rubber stop D.50mm

Height 50 to 64 mm | Thread M8 to M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
9.24 € HT Piece
11.09 € TTC
Available
-
+
Print
Features
Reference
LE TP50
Material
Steel
Thread
isometric
Height
64 mm
Thread height
35 mm
Thread diameter
M8
Diameter
50 mm
Hardness
65

Conical rubber stop D.50mm

Height 50 to 64 mm | Thread M8 to M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
7.05 € HT Piece
8.46 € TTC
Available
-
+
Print
Features
Reference
LE TP5050
Material
Steel
Thread
isometric
Height
50 mm
Thread height
20 mm
Thread diameter
M8
Diameter
50 mm
Hardness
60

Conical rubber stop D.50mm

Height 50 to 64 mm | Thread M8 to M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
7.43 € HT Piece
8.92 € TTC
Available
-
+
Print
Features
Reference
LE TP5050M10
Material
Steel
Thread
isometric
Height
50 mm
Thread height
25 mm
Thread diameter
M10
Diameter
50 mm
Hardness
60

Conical rubber stop D.50mm

Height 50 to 64 mm | Thread M8 to M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
7.05 € HT Piece
8.46 € TTC
Unavailable
-
+
Add to cart
Print
Features
Reference
LE TP5058
Material
Steel
Thread
isometric
Height
58 mm
Thread height
20 mm
Thread diameter
M8
Diameter
50 mm
Hardness
60

Conical rubber stop D.50mm

Height 50 to 64 mm | Thread M8 to M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
7.85 € HT Piece
9.42 € TTC
Unavailable
-
+
Add to cart
Print
Features
Reference
LE TP5058M10
Material
Steel
Thread
isometric
Height
58 mm
Thread height
25 mm
Thread diameter
M10
Diameter
50 mm
Hardness
60

Conical rubber stop D.50mm

Height 50 to 64 mm | Thread M8 to M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
7.85 € HT Piece
9.42 € TTC
Unavailable
-
+
Add to cart
Print
Features
Reference
LE TP5065M10
Material
Steel
Thread
isometric
Height
65 mm
Thread height
25 mm
Thread diameter
M10
Diameter
50 mm
Hardness
60

Conical rubber stop D.50mm

Height 50 to 64 mm | Thread M8 to M10

Reference
Silentblocks are used to reduce vibrations, shocks or noise by equipment. The part is composed of a metal connection part and a NBR damping part. Not compatible with Oil and Gas.
8.27 € HT Piece
9.92 € TTC
Available
-
+
Print
Features
Reference
LE TP50A
Material
Steel
Thread
isometric
Height
65 mm
Thread height
20 mm
Thread diameter
M8
Diameter
50 mm
Hardness
60
