Damped Threaded Gas Spring - Rod 10mm

Damped of 65% | Stroke 500 mm | F1 Max 300N

1. Reference

The damped gas spring contains an internal oil volume of 65%, these gas springs provide only damping at the rod end. The rod retraction is free. Caution: the maximum force is reduced, progression very high.

Print

Damped Threaded Gas Spring - Rod 10mm

Damped of 65% | Stroke 500 mm | F1 Max 300N

1. Reference

The damped gas spring contains an internal oil volume of 65%, these gas springs provide only damping at the rod end. The rod retraction is free. Caution: the maximum force is reduced, progression very high.

2. Enter the force
Your gas spring reference will be :
45.32 € HT Piece 60.43 €
54.38 € TTC
Available
-
+
Print
Features
Reference
ST A500VD10NM+F1
Material
Steel
Rod end fitting
M8 Threaded Gas Spring
Tube end fitting
M8 Threaded Gas Spring
Stroke
500 mm
Rod diameter
10 mm
Tube diameter
22 mm
Rod thread diameter
M8
Tube thread diameter
M8
Extended length
1055 mm
Gas spring min. force
0 N
Gas spring max. force
300 N
Rod material
Nitrided steel
Tube material
Black epoxy painted steel
End type
Threaded (No end fittings)
Valve
No
Hole
8.2 mm
